PE5420-M Vacuum Epoxy Encapsulated Safety Isolation Transformer, PCB Welding, 15VA, 220V Input, 6V/2.5A Output, CE Certified (15VA-230V 15V)

The PE5420-M is a vacuum epoxy encapsulated safety isolation transformer designed for PCB welding applications. With a power rating of 15VA, it accepts a 220V primary input (pins 1-7) and delivers a reliable 6V/2.5A secondary output (pins 9-13), making it well-suited for a wide range of electronic circuits and power supply designs. The vacuum epoxy encapsulation process provides outstanding resistance to moisture, dust, and vibration, ensuring long-term stability and consistent performance even in demanding environments. Its compact PCB-mount design allows for straightforward integration into circuit boards, delivering secure and dependable electrical connections. The single-phase encapsulated coil structure contributes to enhanced durability, while the high-pot test rating of 3.5KV underscores its robust insulation integrity. Compatible with 50/60Hz systems, this transformer is a versatile choice for engineers and hobbyists alike who require a reliable isolation solution for sensitive electronic equipment.

• ELECTRICAL SPECIFICATIONS: This PE5420-M transformer features a 15VA power rating, 220V primary input voltage, and a 6V/2.5A secondary output for reliable power delivery.
• VACUUM EPOXY ENCAPSULATED: The fully encapsulated coil structure provides superior moisture and dust resistance, ensuring enhanced durability and long-term operational stability.
• PCB WELDING DESIGN: Compact PCB-mount construction allows for straightforward board-level integration, ensuring secure and reliable electrical connections in your application.
• SAFETY ISOLATION TRANSFORMER: Designed to electrically isolate input from output, helping to protect sensitive equipment and circuits from power surges and electrical noise.
• SINGLE PHASE CONSTRUCTION: This single-phase encapsulated transformer is built for consistent performance and is suitable for a wide range of power supply and electronic applications.
