Generator Set Speed Electronic Governor Board 4914090 4914091 Slow Start Control Module Governor (Size : 4914090)

The main technical parameters1. Working environmentAmbient temperature: -15～＋55 ℃Relative humidity: 0-95%Vibration: 25 HZ 2 mm2. PowerWorking voltage: 24 ±6 V DCGrounding method: negative grounding (body)Maximum operating current: 2.5A, 24VAppearance1. Module size: 150*105*40MM2. The module shell is made of aluminum, and the surface is treated with plastic spraying.3. The inside of the module is sealed with epoxy resin4. According to the following data, make holes in the appropriate parts. It is recommended to install with non-slip self-locking screwsThe center distance of the four mounting holes is: 135*102MM, and the diameter of the mounting holes is 5.5MM3. Main technology:1. Working environment range -40 degrees to 85 degreesMaximum operating temperature range 95%Storage temperature -55 degrees to 92 degreesVibration 20-100HZ 500mm/Sec.2. Power supplyPower supply voltage 12 and 24V DC battery systemGrounding polarity negativePower consumption 40MaActuator continuous current, minimum 1A maximum 4.5ASpeed ​​sensor signal 2 to 120V RMS3. Technical specificationsRotation speed is qualitatively better than plus or minus 0.25%Speed ​​range 1KHz to 6.5KHzMaximum thermal stability plus or minus 0.7%IDLE adjustment 360 plus or minus 20Hz 85% of the rated speedDROOP adjustment, the minimum position is 15Hz plus or minus 6HZ/load current change per ampereMaximum position 400Hz plus or minus 75Hz/load current change per ampereExternal speed adjustment plus or minus 200Hz (external 1K)AUX input sensitivity 148Hz /1V plus or minus 1HzFour. Wiring instructions1. Foot: power supply positive (DC24+) input2. Foot: negative power supply (DC24-) input3, 4 feet: actuator (no positive and negative) output5. Foot: positive input of speed sensor6. The negative input of

• ★The speed control board is made of high-quality materials, flame-retardant, high-temperature resistant, long service life, and safe to use
• ★This speed control board is a brand new high-quality interface module that can provide you with the most stable performance
• ★Easy to install, with instructions, use immediately after installation, fast and convenient
• ★Imported electronic components, more stable performance, greatly improving the service life of the engine
• ★You can contact us at any time if you encounter problems during the purchase process, we will solve it for you in the first time
