APIELE 10 Amp 22mm Latching Push Button Switch 12V Angel Eye LED Waterproof Stainless Steel Round Self-Locking 7/8'' 1NO 1NC 2 Pack (10 Amp/White Led)

All New Design 10A Ring Led Latching Push Button Switch Suitable for automobile, motorcycle modification, switch modification of control equipment. Latching switch The Latching switch will remain on once it ispressed and stay on until it is pressed again. Specification: - Switch Rating: 18A/250VAC, 10A/12VDC - Operation Temperature: -20 ℃ ~ +55℃ - Mechanical life: 2,000,000 cycles ( Old type is 1,000,000 cycles) - Electrical life: 500,000 cycles ( Old type is 100,000 cycles) - Panel thickness: 1 - 10mm - Protection level: IP65, IK10 - Mounting Cut Hole: 22mm - Operation Type: Latching- Switch Contact: 1NO 1NC - LED Rating: 5 MA, AC/DC 12V - LED Pattern: Ring Indicator - LED Life: 100,000 hours - Contact Material: Silver alloy - Button Material: Stainless Steel Note: - The switch come with a rubber O-ring whichmakes it splash resistant but it can NOT be submerged underwater. Packing Include: 1 x All New Design 22mm push button switch,1 x pigtail socket

• The information below is per-pack only
• Suitable for automobile, motorcycle modification, switch modification of control equipment.
• Brand All New Design Silver 10A Stainless Steel Ring LED Pushbutton Switch; LED voltage: 12V only, Hole size required: 7/8''/22mm
• 22mm Latching Push Button Switch: Push it, ON; Push it again, OFF. Contact Configuration: 1NO1NC
• 4.8 mm wide X 0.8 mm thickness Terminal Pin for High Current Use; Longer work life: Electrical life: 100,000 times. Mechanical Life: 1,000,000 times.
• High quality metal material & IP65 waterproof protection can be used in wet or dusty enviroment.
